Description
ViewSonic EP1052T-H 10.1" Interactive Meeting Room Scheduling Panel with PoE+, NFC, RFID, HID Access Control and Built-In Wi-Fi
Streamline meeting room scheduling, workplace communications, and secure room access with the ViewSonic EP1052T-H 10.1" Interactive Scheduling Panel. Featuring a 1280 x 800 IPS-type touchscreen, 350-nit brightness, 10-point projected capacitive touch technology, built-in dual-band Wi-Fi, and Power over Ethernet (PoE+), this professional panel delivers a versatile solution for modern meeting spaces.
Designed for enterprise environments, the EP1052T-H combines NFC/RFID and HID badge support, an integrated camera, microphone, stereo speakers, GPIO connectivity, and door access control capabilities in a compact, wall-mountable device.
Clear 10.1" Interactive Touchscreen
The EP1052T-H features a 10.1-inch IPS-type display with 1280 x 800 resolution, providing clear visibility for room schedules, meeting information, and interactive applications.
With 350 cd/m² brightness, a 1000:1 static contrast ratio, and 160-degree viewing angles, the screen delivers readable content in professional indoor environments.
Its anti-glare surface, 3H hard coating, and protective glass provide added durability for frequently used meeting spaces.
Responsive 10-Point Capacitive Touch
Navigate scheduling applications and interactive content using the 10-point projected capacitive touchscreen.
The responsive touch interface allows employees and visitors to check meeting room availability, review reservations, and interact with supported scheduling software.
It is also suitable for interactive directories, information kiosks, and on-demand digital signage.
Intelligent Meeting Room Scheduling
Simplify meeting room reservations with compatibility for professional scheduling platforms, including EMS, Planon, Appspace, and Pronestor.
When configured with compatible scheduling software, the EP1052T-H can display room availability, upcoming reservations, and meeting details.
Employees can conveniently locate available spaces, check in for meetings, and manage reservations through supported applications.
Integrated LED Room Availability Indicator
The EP1052T-H includes a programmable multicolor LED surround light that projects onto the wall.
This illuminated indicator allows employees to identify meeting room availability from a distance, reducing interruptions and improving workplace efficiency.
Lighting behavior and colors can be configured through compatible software.
Power over Ethernet for Simplified Installation
Reduce installation complexity with PoE+ connectivity, which allows the panel to receive power and network data through a single Ethernet cable.
This eliminates the need for a separate power outlet when connected to compatible PoE+ networking equipment.
The streamlined installation is particularly useful for conference room entrances, office corridors, and large-scale scheduling deployments.
Built-In Dual-Band Wi-Fi
The EP1052T-H features built-in 802.11ac Wi-Fi, supporting both 2.4GHz and 5GHz wireless networks.
Wireless networking provides additional installation flexibility when an Ethernet data connection is not preferred.
The display also includes a 10/100/1000 Mbps RJ45 Ethernet connection for wired networking.
Unlike models that require an external USB wireless adapter, the EP1052T-H includes integrated Wi-Fi connectivity.
NFC, RFID and HID Access Control
Enhance meeting room security with integrated NFC, RFID, and HID card-reading capabilities.
The panel supports 13.56MHz NFC and 125kHz RFID, allowing compatible employee credentials to be used with supported access control systems.
Its Wiegand, GPIO, and RS485 interfaces provide additional integration options for electronic door locks and building access systems.
When connected to appropriately configured hardware and software, the EP1052T-H can help manage authorized access to meeting spaces.
Integrated Camera and Optical Scanner
The EP1052T-H includes a built-in camera and optical scanner for compatible interactive applications.
These features support QR-code-based workflows, identification functions, and additional meeting room management capabilities when used with appropriate software.
Two-Way Audio Communication
Improve communication between visitors and meeting room occupants with an integrated microphone, acoustic echo cancellation, and dual 2W speakers.
These features support compatible two-way communication applications, allowing reception staff or visitors to communicate with people inside a meeting space.
The panel also includes dedicated microphone input and audio output connections.
Android-Based Embedded Platform
The EP1052T-H supports Android 9.0 APIs and HTML5-based applications, enabling integration with compatible room scheduling, signage, and enterprise software.
Its 16GB eMMC storage supports local application data and compatible multimedia content.
The embedded platform reduces the need for an external computer for supported applications.
Signage Manager Express Software
Create and manage digital signage content using ViewSonic Signage Manager Express.
The software allows users to transfer compatible multimedia content from Windows computers, organize playback schedules, and configure digital signage presentations.
This makes the EP1052T-H suitable for room scheduling as well as interactive information displays and workplace communications.
Enterprise Security Features
The EP1052T-H supports enterprise-oriented security technologies, including SCEP, Android Enterprise APIs, IEEE 802.1X, and network encryption.
These capabilities help IT administrators integrate the panel into supported corporate networks and device management environments.
Flexible Wall and Glass Mounting
Install the panel on a wall or compatible glass surface using the included flush wall mount bracket and glass mounting tape.
Its compact design and integrated cable management provide a clean appearance for meeting room entrances and reception areas.
The display supports both landscape and portrait orientations for flexible deployment.
Reliable Commercial Operation
Designed for professional indoor environments, the EP1052T-H supports 16 hours of operation per day, seven days per week.
Its LED backlighting features a 10,000-hour rated lifespan, making it suitable for scheduled workplace and commercial applications.
